YJJ 17124975-5 Electrochemical Sulfur Dioxide SO2 Gas Sensor for MX6 iBrid Six-in-One Gas Detector

Product Description:

YJJ 17124975-5 Electrochemical Sulfur Dioxide SO2 Gas Sensor for MX6 iBrid Six-in-One Gas Detector

Features:

I. Model and Order Number

Model / Part Number: 17124975-5

Corresponding Gas: Sulfur Dioxide (SO₂)

Applicable Models: MX6 iBrid Six-in-One Gas Detector (Special Replacement Sensor)

Sensor Type: Electrochemical

II. Core Parameters

Detected Gas: Sulfur Dioxide (SO₂)

Range: 0–150 ppm

Resolution: 0.1 ppm

Response Time T90: ≤ 30 s

Operating Temperature: -20°C ～ +55°C

Humidity: 15%–95% RH (No Condensation)

Life Span: 2 Years (Normal Environment)

Output: Linear Current Output, Automatically Identified by MX6 Host

Package: MX6 Special Cylindrical Type, 3-pin Connector

Features: Strong Anti-interference, Good Selectivity, Plug-and-Play, Factory Calibration

III. Main Applications

Oil / Chemical: Refining, Coal Chemicals, Sulfuric Acid Factory SO₂ Leakage and Process Monitoring (Toxic, Irritating).

Environmental Protection / Emission: Power Plants, Boilers, Incinerators SO₂ Concentration Monitoring, Compliance with Emission Standards.

Metallurgy / Mines: Non-ferrous Metal Smelting, Roasting Process Toxic Gas Detection, Poison Prevention.

Municipal / Tunnel: Underground Pipe Laying, Tunnel, Waste Incineration Site SO₂ Environmental Monitoring.

Industrial Safety: SO₂ Highly Toxic (Corroding Respiratory Tract), Real-time Alarm and Protection at the Scene.

IV. Comparison with the Same Series (Quick Reference for MX6 Sensors)

17124975-1: CO (0–1500 ppm)

17124975-2: H₂S (0–500 ppm)

17124975-3: O₂ (0–30% VOL)

17124975-4: NO₂ (0–20 ppm)

17124975-5: SO₂ (0–150 ppm)

17124975-6: NH₃ (0–100 ppm)
